Description
White Rodgers Line Voltage Thermostat Part Number 1G65-641.
Line Voltage Mechanical Thermostats Baseboard and Resistance Heat.
Specifications:
- Range: 40 to 80F (4 to 26C)
- Differential: 3.0F 1.5C
- Switch Action: Open on Rise
- SPST
- Amperage: 22.0, 2500W at 120 Vac, 22.0, 5000W at 240 Vac, 18.0, 5000W Resistive at 277 Vac
- Typical Applications: Baseboard Electric Heat, Cable Heat, Glass Panels
- U.S Markets Only: Yes
- Overall Dimensions: 4.81H X 3.31W X 1.44D
- Approvals: U.L. listed and C.S.A. certified
- Dimensions: 4.81 H X 3.31 W X 1.44 D
- Agency: U.L. listed and C.S.A. certified
Features:
- Rugged bimetal switch action
- 1G65 types are a single-pole models
- Thermostat mounts on 2 X 4 electrical box
- Classic white
- Mercury free design
